MEANWell LPV-60-12 LED Power Supply

Description

MEANWell LPV-60-12 LED Power Supply

Features:
Constant voltage design
Universal AC input / Full range
Withstand 300VAC surge input for 5 seconds
Protections: Short circuit / Over load / Over voltage
Cooling by free air convectionFully encapsulated with IP67 level (Note.8)
Fully isolated plastic caseIIClass power unit, no FGClass 2 power unit
ass LPSPSuitable for LED lighting and moving sign applications (Note.7)
100% full load burn-in test
Low cost, high reliability
2 years warranty

Output:
Power: 12V 5A 60W
Voltage Tolerance: 5%
Setup, Rise Time: 500ms, 20ms/230VAC 500MS,20ms/115VAC at Full load

Input:
Voltage Range: 90-264VAC / 127-370VDC
Frequency: 47-63HZ
Efficiency: 83%

Over load: 110-150% rated output power
Over Voltage: 13.8-16.2V
Working Temp: -30 to +70 degree
Working Humidity: 20-90% RH non-condensing

Authentication: UL CE CB EMC IP67
Size: 162.5*42.5*32mm
Weight: 0.4KG

More Detail: Meanwell LPV-60-12
