Colorlight X16E-3D LED Controller

Description

Colorlight X16E-3D is a powerful video signal controller with 16 Gigabit Ethernet ports.
It supports 4K inputs via DP 1.4 and HDMI 2.0, as well as 2K inputs via HDMI 1.4 and DVI.
It offers flexible screen control and high-quality image display through its range of practical functions.

.Input ports: 1×DP 1.4, 1×HDMI 2.0, 2×HDMI 1.4, 2×DVI
.Loading capacity: 10.48 million pixels, maximum width: 16384 pixels, or maximum height: 8192 pixels
.Input resolution: up to 4096×2160@60Hz, supporting customized setting
.Output ports: 16×Gigabit Ethernet ports
.Support video source switching, cropping, splicing and scaling
.Support up to 6 windows, of which the location and size can be freely adjusted
.Support precise color management and display gamut adjustment
.Support video sync
.Separate audio input and output
.Support analyzing and outputting the audio signals of HDMI and DP inputs
.Support LAN control
.Support control via hand-held terminal (app)
.Support RS232 protocol control
.Support 3D
.Support HDCP
.Support brightness and color temperature adjustment

Size: W×H×L/482.6mm×103.0mm×415.1mm
Weight: 6KG
