Colorlight Z5 LED Video Controller

Description

Colorlight Z5, a new generation of professional LED video controller, is designed specially to meet the ultra-low latency display, HDR and wide color gamut needs of live event, broadcast, television, filming and other scenarios, where real time, low-latency processing and color fidelity is required for Ultra HD image and LED display control. Z5 includes features providing excellent vision effect for user.
Features
Input
.Full 4K inputs: HDMI2.0, DP1.2, 12G-SDI.
.Single port supports up to 4096 ×2160@60Hz.
.Support 8bit / 10bit video signal input.
.Support HDCP1.4/HDCP2.2.
.Support input frame rate from 23.98Hz to 240Hz.
Output
.Maximum capacity of 13.1 million pixels, with maximum 16384 pixels in width or 8192 pixels in height.
.20-channel Gigabit Ethernet port output; 2-channel 10 Gigabit fiber port output, choose any of two types.
.Support output frame rate of 23.98Hz to 240Hz.
.Support both Ethernet port redundancy and controller redundancy.
Video processing
.Video cropping, broadcasting level switching and scaling.
.Up to 3-window display, support 1-channnel 4K and 2-channel HD signal display.
.Low latency, minimum one frame delay.
.HDR10 / HLG display.
.Genlock function.
Color adjustment
.Picture adjustment for hue, saturation, contrast, and brightness compensation.
.Brightness adjustment, support network port grouping brightness adjustment.
.Color temperature adjustment with precision and RGB independent adjustment.
Control
.USB port for control and cascading.
.RS232 port.
.LAN port for TCP/IP control.

Powe：AC100-240V, 50 / 60Hz
Size：482*407*88
Weight：5.9KG
