F3.75 P4.75 Indoor SMD einfarbige LED-Modul
Matrix LED module
One Order over 500 USD Free of delivery;
Over 1500 USD 5% discount;
Over 3000 USD 10% discount.
Over 1500 USD 5% discount;
Over 3000 USD 10% discount.
Specfication: PH4.75
Pixel Pitch: 4.75mm
Density of Pixel: 44321/m²
Pixel constitution: 1Ror1G
Size of Module: 304*152mm
max power per module: 23W
Moudle Resolution: 64*32
$26.40
1984 vorrätig
Beschreibung
F3.75 P4.75 Indoor SMD single color LED module
|
Unit Module
|
Specfication
|
PH4.75
|
|
Pixel Pitch
|
4.75mm
|
|
|
Density of Pixel
|
44321/m²
|
|
|
Pixel constitution
|
1Ror1G
|
|
|
Size of Module
|
304*152mm
|
|
|
max power per module
|
23W
|
|
|
Moudle Resolution
|
64*32
|
|
|
Major technical Parameters
|
The Optimum View Distance
|
≥5m
|
|
The Optimum View Angle
|
100°
|
|
|
Maximum Power consumption
|
400W/m²
|
|
|
Console Method
|
Synchronization control(Asynchronous control)
|
|
|
Driving Components
|
595 Drving
|
|
|
Driving Method
|
1/16 Scan
|
|
|
Frame Frequency
|
≥60Hz
|
|
|
Refresh rate
|
≥120Hz
|
|
|
Luminance of white balance
|
≥140
|
|
|
Working environment temperature
|
-10°c~50°c
|
|
|
Working voltage
|
220V±15%
|
|
|
Grey Scale/Color
|
Display Colors≥16.7M(Synchronized)
|
|
|
Brightness adjustment
|
256 Levels of each color(R,G,B)can be adjusted manually and 8 levels of each color can be adjusted antomatically
|
|
|
Input signal
|
RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc.
|
|
|
Control ststem
|
PCTV mon-linear editting card+DVI display card+main controller card+optic fibre transmiddion(Optional)
|
|
|
Mean Time Between Failure
|
≥1000hours
|
|
|
Life Span
|
10000hours
|
|
|
Out-of-contronl Rate
|
<0.0002
|
You'd better buy all modules at a time for one led screen, in this way, we can make sure that all of them are of the same batch.
For different batch of LED modules have a few differences in RGB rank, color, frame, brightness etc.
So our modules can't work together with your previous or later modules.
If you have some other special requirements, please contact our online sales.
Zusätzliche Information
| Gewicht | 0.7 kg |
|---|
